DETAILED DESCRIPTION The Industrial Conveyor Dishwasher with Drying Function (Model HT-P1X1H) is a professional machine developed by HATTON for the continuous and efficient washing of large volumes of tableware in restaurants, hotels, professional kitchens, canteens, catering companies, and food-service establishments requiring a high-productivity solution for continuous operation. With overall dimensions of 2,600 × 850 × 1,900 mm, a machine inlet width of 586 mm, and a maximum washing capacity of up to 2,000 dishes per hour, the HT-P1X1H is designed for continuous tableware processing through a 530 mm wide mesh conveyor belt. Its maximum washing height is 150 mm, allowing it to process plates and items compatible with the specified entrance dimensions. The system operates at a washing temperature of 55-60 °C and a rinsing temperature of 82 °C. The machine incorporates electric heating with a power requirement of 57 kW and requires a 380 V, 50 Hz, 3N electrical supply or a customized configuration. It also features a drying function with a power requirement of 9.55 kW to complete tableware treatment after the washing and rinsing stages. The HT-P1X1H requires an inlet water pressure of 0.15-0.4 MPa and an inlet steam pressure of 0.3-0.4 MPa. Its configuration is designed for professional facilities seeking to automate tableware washing and drying, maintain a continuous workflow, and process large volumes during food-service operations. TECHNICAL SPECIFICATIONS: Model: HT-P1X1H. Equipment type: Industrial conveyor dishwasher with drying function. Application: Professional and continuous washing and drying of tableware and utensils. Overall dimensions: 2,600 × 850 × 1,900 mm. Weight: 429 kg. Machine inlet width: 586 mm. Mesh belt width: 530 mm. Maximum washing height: 150 mm. Maximum washing capacity: 2,000 dishes per hour. Water consumption: 280 liters. Washing temperature: 55-60 °C. Rinsing temperature: 82 °C. Inlet water pressure: 0.15-0.4 MPa. Steam inlet pressure: 0.3-0.4 MPa. Drying power: 9.55 kW. Electrical supply: 380 V / 50 Hz / 3N or customized. Heating method: Electric heating. Electric heating power: 57 kW. Transport system: Mesh conveyor belt. DESIGN AND TECHNOLOGY FEATURES: Mesh Conveyor System: The HT-P1X1H incorporates a 530 mm wide mesh conveyor belt that continuously transports tableware throughout the washing process. High Processing Capacity: With a maximum capacity of up to 2,000 dishes per hour, the machine is designed for professional facilities requiring high-volume tableware processing. 586 mm Entrance Width: The 586 mm machine inlet width facilitates the continuous feeding of tableware into the washing system. 150 mm Maximum Washing Height: The maximum washing height determines the dimensions of items compatible with the washing process. 55-60 °C Washing Temperature: The system operates within this temperature range during the main washing stage. 82 °C Rinsing Temperature: The rinsing stage operates at 82 °C to complete the tableware treatment process. Electric Heating System: The machine uses electric heating with a power requirement of 57 kW to provide the required thermal conditions during operation. Drying Function: The HT-P1X1H incorporates a drying function with a power requirement of 9.55 kW to complete tableware treatment after washing and rinsing. Flexible Electrical Configuration: The model can operate with a 380 V, 50 Hz, 3N electrical supply or a customized configuration according to installation requirements. Water Pressure Control: The required inlet water pressure ranges from 0.15 to 0.4 MPa. Steam Inlet: The machine accommodates an inlet steam pressure of 0.3-0.4 MPa. Continuous Washing and Drying: The combination of the conveyor system, washing process, and drying function allows a continuous tableware flow during professional operations. Professional-Duty Construction: The HT-P1X1H is designed for restaurants, hotels, professional kitchens, and other facilities requiring an industrial tableware washing and drying solution. INDUSTRIAL APPLICATIONS: The HT-P1X1H model is particularly suitable for: • Restaurants and food-service establishments. • Hotels and hospitality establishments. • Professional kitchens. • Industrial kitchens. • Institutional canteens. • School and university dining facilities. • Catering companies and food-service providers. • Central kitchens. • Large-scale food-service companies. • Medium and high-volume hospitality facilities. • Businesses processing large quantities of tableware. • Facilities requiring continuous conveyor-based washing and drying. • Food-service businesses seeking to automate tableware washing and drying. • Professional facilities requiring a capacity of up to 2,000 dishes per hour. KEYWORDS: HT-P1X1H industrial dishwasher, HT-P1X1H, HATTON HT-P1X1H, industrial conveyor dishwasher, commercial conveyor dishwasher, industrial dishwasher with drying function, 2,000 dishes per hour industrial dishwasher, 2,000 dishes per hour dishwasher, industrial dishwashing machine, professional dishwasher, restaurant dishwasher, hotel dishwasher, industrial kitchen dishwasher, professional kitchen dishwasher, catering dishwasher, canteen dishwasher, industrial mesh belt dishwasher, dishwasher with mesh conveyor belt, 57 kW industrial dishwasher, 9.55 kW drying dishwasher, 380 V industrial dishwasher, 380 V 50 Hz 3N dishwasher, HATTON commercial dishwasher, high-capacity industrial dishwasher, industrial dishwasher for hospitality, continuous conveyor dishwasher, electric industrial dishwasher, industrial dishwasher with drying function, industrial tableware washing machine, industrial dishwashing equipment, hospitality equipment, industrial food-processing machinery.
